The versatile sealers that suit your needs.

Case Erectors

Product Features

A complete system

The CASE-IT series offers a wide range of case sealing and erecting systems. Their compact size and high reliability make them a very popular product. Simple and easy to use machine with ergonomic features to cover a vast range of industries: cosmetic, pharmaceutical, food, beverage, industrial product. The motorized belt conveyor eases the product transfer into the taping heads for the ultimate seal with the top squeezers.

Base Model Key Attributes

  • Adjust manually for uniform or different box sizes by crank handle
  • High speed and durable taping head
  • Dual telescoping mast with cushion
  • Both side compression rollers
  • Stainless roller table
  • Easy operation and easy maintenance
Production Challenges
SALS SERIES

Technical Features

KSSA1.0 Series Comparison
KSSA1.0-SB Semi-automatic KSSA1.0-BTB Semi-automatic KSSA1.0-TB Semi-automatic KSSA1.0-SS Semi-automatic
Key additional features
  • Side belt driven
  • Suitable for standard boxes
  • Top and bottom belt driven
  • Suitable for tall/slim size boxes
  • Two side guiding rails
  • Stainless steel table
  • Top and side belt driven
  • Suitable for heavier loads, up to 40kg
  • Top and bottom belt driven
  • Suitable for flat boxes side seal
Power supply 1ph, 120V 1ph, 120V 1ph, 120V 1ph, 120V
Min. box dimensions L x W x H 6" x 4.5" x 4.5" 6" x 7" x 4.5" 6" x 5" x 4.5" 6" x 10" x 4.5"
Max. box dimensions L x W x H ∞ x 19.5" x 19.5" ∞ x 19.5" x 19.5" ∞ x 19.5" x 19.5" ∞ x 23.5" x 9.5"
Tape width 2" 2" 2" 2"
Working height 22.5" to 30" 22.5" to 30" 22.5" to 30" 22.5" to 30"
Conveyor speed (ft/m) 65 65 65 65
Machine dimensions L x W x H 50" x 38" x 56" 43.5" x 31" x 56" 50" x 38" x 56" 37" x 46.5" x 56"
Air requirements (PSI) N/A N/A N/A N/A
OPTIONS
Infeed and outfeed conveyor - 20" long
3" tape head
No tape alarm
Safety doors with auto stop
Stainless steel upgrade
Case format keeper (memory mode)
Custom case dimensions
Labeler integration
Printer integration
